Frigidaire Dishwasher Error Codes List: Every Code Explained
Every Frigidaire dishwasher error code we could verify against Frigidaire's own documentation — what it means, what usually causes it, and the first fix to try — in one table. Codes differ between model series, so treat your model's tech sheet as the final word.
How to read and retrieve error codes on Frigidaire dishwashers
Frigidaire dishwashers include a diagnostic/water test cycle (entered by holding specific pad combinations — on many Gallery models, holding Power Scrub/Start combinations; the service data sheet behind the toe-kick gives the exact pair) that fills, washes, heats and drains in a compressed sequence and shows any i-code that the control logs.
The complete Frigidaire dishwasher error code list
| Code | Meaning | Most likely cause | First fix |
|---|---|---|---|
| CL | Close dishwasher door prompt (rendering used on GLD/FDB-series manuals; same instruction as Cd on other models) | Door has been left open or not properly latched | Close the dishwasher door and latch it fully; ensuring the door is properly latched clears the display and no service is needed |
| Cd | Close dishwasher door prompt (rendering used on FGHD-series manuals; same instruction as CL on other models) | Door has been left open or not properly latched | Close the dishwasher door and latch it fully; the status lights flash to show cycle status until it is latched |
| E20 | Platform-rendering variant of the drain fault on some Frigidaire/Electrolux platforms (E20 = drain system in those charts) — the i20 playbook applies. | Clogged filter | Clean/clear the chain; service or replace the pump as found. |
| E30 | Platform-rendering variant in the drain family on some Frigidaire/Electrolux platforms (E30-style codes appear in the drain/leak monitoring area by platform); diagnose with the i20/i30 playbooks by symptom. | Drain restriction (tub holding water) | Drain branch: clean filter, clear path, service pump. Flood branch: dry base, find and fix the leak. |
| ER | 'Er' on a Frigidaire dishwasher display = a keypad/control error state (Er followed by a key code on many models indicates a stuck/shorted key or control fault). | Moisture/cleaner in the panel | Dry-out first; reseat the panel ribbon (power off) if it persists. |
| HO | Water heat delay; the display flashes while the cycle waits for the water to heat | Incoming water is not yet at the temperature the cycle needs | No action is needed; washing continues automatically once the water reaches temperature |
| Hd | Water heat delay (older-model rendering of HO) | Incoming water is not yet at the temperature the cycle needs | No action is needed; washing continues automatically once the water reaches temperature |
| LO | Rinse aid dispenser is low and needs to be refilled | Rinse aid level in the dispenser has run low | Refill the rinse aid dispenser; the indication stays through up to 5 cycles or until the reservoir is filled |
| PF | Power failure notice; appears when the dishwasher is first installed or when power has been interrupted | Power outage or interrupted supply during a cycle (soft failure pauses, hard failure stops the unit) | Touch the START/CANCEL pad to clear it; on newer models press Start within 18 hours of a hard failure to resume at the interruption point |
| UO | Vent open error — the dishwasher's vent (drying vent) is reporting open/not operating correctly during the heated dry phase. | Vent fan/damper motor failure | Clean the vent passage; replace the vent assembly if its motor is dead; repair door-harness damage if found. |
| i10 | Fill error — the dishwasher is not filling with water in the expected time (low/no water inlet). | Supply off/restricted | Free the float; restore supply; clean screen; replace a dead valve. |
| i20 | Drain error — the dishwasher is draining too slowly or not at all (i20 family; iF0/iE0 siblings cover related drain/filter states by model). | Clogged filter | Clean/clear the path; clear pump debris or replace a dead pump (continuity test). |
| i30 | Leak/flood error — water detected in the base (anti-flood system active); the dishwasher may drain continuously. | A genuine leak | Repair the leak found; correct detergent if suds were the cause. |
| i40 | Clogged filters or a restricted drain line has been detected (grouped with i20 and iF0) | Soiled filters or sump area, or a pinched or blocked drain hose | Check and clean both filters and the sump area and check for a pinched or blocked drain hose; if the drain line is attached to a disposer, check that the knockout plug has been removed |
| i60 | A problem has been detected with the water heating system | Water heating system fault detected by the electronic control | Press the cancel button or turn power off at the breaker for 5 minutes and restart; if this does not resolve the problem, service will need to be called |
| iC0 | A problem has been detected with the electronic control system (fold 'ico') | Electronic control system fault detected by the control | Press the cancel button or turn power off at the breaker for 5 minutes and restart; if this does not resolve the problem, service will need to be called |
| loc | Controls locked; the status window shows loc while the child lock / control lock is on | The DELAY START pad was held until loc displayed, locking the controls against accidental changes | Press the DELAY START pad again until loc is no longer displayed in the status window |
How to reset / clear error codes on Frigidaire dishwashers
Frigidaire's i-series codes clear with a power reset: switch the breaker off for at least 5 minutes, restore power, and run a cycle. Leak code i30 is the exception in practice — it will not stay cleared while water remains in the base pan, because the float switch is still physically lifted.
How to diagnose any Frigidaire dishwasher code
Work the problem in this order: (1) record the code exactly, including any flashing tap or salt/rinse-aid symbols shown with it; (2) establish the water story — is there water in the base, is the tub dry, did the cycle stop early or never start — because dishwasher codes split into leak, fill, drain and heating families; (3) run the external checks first: supply tap and inlet hose for fill codes, filters, sump and drain hose for drain codes, and for leak codes, dry the base and watch where water appears on a short test cycle; (4) clear the code and re-run the shortest programme while observing — most dishwasher faults announce themselves in the first ten minutes; (5) replace parts last, in the order the code family suggests. A leak code in particular should never be cleared and ignored: the float that raised it is the only thing between a small leak and a floor.
Frigidaire codes: the i-family and the Er header
Frigidaire dishwashers report in two styles. Current models use the i-family — i10, i20, i30 and their relatives — where the digit after the i names the system (fill, drain, leak/flood). Older and simpler models show Er as a header, and the letters or the key that lights alongside Er carry the actual diagnosis, most often a stuck or shorted key in the touch panel. Treating Er alone as a complete code is the classic Frigidaire search mistake: capture the whole display state, including which key is lit, before you search or call anyone.
The Frigidaire drain chain, in order
Frigidaire drain faults (the i20 family) usually arrive gradually: the fine filter and the sump's glass trap collect debris in a way that strangles drainage over weeks, so the machine sounds different at drain time and leaves the sump dirtier long before it codes. The order that finds it: bottom rack out, filter assembly and glass trap lifted and washed, spray arm checked for anything hanging into the sump, then a timed cancel/drain — a healthy Frigidaire empties decisively, a strangled one trails off. Only after the path is proven clean does the drain pump itself become the suspect.
Status words that are not faults at all
A share of Frigidaire "codes" owners search for are the machine simply talking: cycle-stage and option displays such as a control-lock indicator, a delay-start readout, or a reminder state. These appear on a healthy machine, clear the way the manual describes (usually a button hold or simply starting the cycle), and never point at a part. The tell is behaviour: a dishwasher that runs its cycle normally while showing the word is displaying a state; a dishwasher that stops, drains unprompted, or refuses to start is reporting a fault, and the fault family is named by what the machine was doing — filling, washing, draining or heating — when it stopped.
The most searched Frigidaire dishwasher codes, in detail
ER — 'Er' on a Frigidaire dishwasher display = a keypad/control error state (Er followed by a key code on many models indicates a stuck/shorted key or control fault).
Frigidaire dishwashers use 'Er' as the header for control/panel errors — commonly a stuck or shorted touch key (the display may pair Er with a key identifier). Moisture and cleaner ingress in the panel is the classic cause, as on every brand's keypad code; a failing control is the other branch. If your display shows Er with the machine otherwise behaving oddly at the panel (beeps, phantom lights), you're in keypad territory.
Most likely cause: Moisture/cleaner in the panel — Steam and sprays — the universal keypad killer.
First check: Power off and dry the panel area thoroughly (hours to a day for moisture cases).
If it keeps coming back: Er returning after dry-outs = dying membrane — replace the panel.
UO — Vent open error
UO is a Frigidaire-specific code for the vent system: many Frigidaire dishwashers use a vent with a small fan/wax-motor damper that opens for drying. UO reports the vent didn't reach or report its expected state (typically flagged around the dry phase). Washing is unaffected; drying suffers. The vent assembly sits at the top of the door on many models — which makes its wiring a door-harness story too.
Most likely cause: Vent fan/damper motor failure — The little vent assembly's drive dies.
First check: Listen/feel at the vent during the dry phase (warm air movement = working vent); note whether UO appears only at dry.
If it keeps coming back: UO returning after an assembly change = harness or control output — check the door harness run.
i10 — Fill error
i10 is Frigidaire's fill code: the valve opened (or should have) and the level didn't arrive. Supply, the inlet valve and its screen, and the float switch veto are the chain — the same fill trio as every brand, in Frigidaire's i-code dialect.
Most likely cause: Supply off/restricted — Under-sink tap, kinked hose, low pressure.
First check: Tap open; float moves freely; listen for fill at start; screen inspection.
If it keeps coming back: Intermittent i10 tracks a float sticking when greasy, or pressure sag at busy times.
i20 — Drain error
i20 means the drain phase timed out: water is leaving too slowly or not at all. Frigidaire's drain chain is filter → sump → pump → hose → air gap/sink, and the blockage lives in it — the filter and the air gap/sink connection are the statistical leaders, the pump the finisher. Frigidaire's owner's guide is unusually direct about what i20 means, and it groups three displays together: i20, i40, and iF0 all report that clogged filters or a restricted drain line have been detected. Its prescribed checks are specific - clean both filters and the sump area, check for a pinched or blocked drain hose, and, if the drain line is attached to a disposer, check that the knockout plug has been removed. It follows that i20 names a restriction, not a failed part: the pump is only suspected once the path it pushes against is proven clear. The guide's general reset for error codes - pressing Cancel, or switching power off at the breaker for 5 minutes - clears the display and lets the unit restart; it does nothing to the restriction itself, which is why a returning code means walking the drain path in order, from filter to sink.
Most likely cause: Clogged filter — The leading cause — a greasy filter throttles everything.
First check: Clean the filter; clear the air gap; check hose run; pump listen test on cancel/drain.
If it keeps coming back: Quick recurrence = downstream restriction or weakening pump.
i30 — Leak/flood error
i30 is Frigidaire's (Electrolux-platform) flood code: the base float/ sensor found water, so the machine stops filling, often runs the drain pump continuously, and refuses cycles. The water came from a leak, an overfill/suds spill-over, or a spill during install. The base must be dried AND the source found — exactly the Bosch E15 / Samsung LC story in Frigidaire's dialect.
Most likely cause: A genuine leak — Hoses, sump/pump seals, a spray arm jetting at a split door seal.
First check: Water supply OFF. Pull out, tilt gently — water out of the base confirms it.
If it keeps coming back: Returning i30 = a drip still arriving; watch a full cycle pulled out.
E20 — Platform-rendering variant of the drain fault on some Frigidaire/Electrolux platforms (E20 = drain system in those charts)
In E-format platform charts, E20 is the drain fault: the machine isn't emptying in time. Everything from the i20 page applies — filter, air gap/sink connection, hose, pump — because the hardware being monitored is the same drain chain regardless of the letters on the display.
Most likely cause: Clogged filter — The leader.
First check: Filter clean; air gap clear; pump listen test on drain.
If it keeps coming back: Fast recurrence = downstream restriction or dying pump.
Less common and model-specific codes
Search data shows owners also meet these codes on Frigidaire dishwashers: AE, CO, E1, E10, E2, E4, E40, EU, F1, F30, F4, F8, H5, I1, I4, ICO, OU, U0, UF. They are not part of the core code list Frigidaire publishes for most models — several are series-specific, abbreviated display readings, or codes carried over from a sister platform — so we do not publish meanings for them rather than guess. Treat them by symptom: note what the machine was doing when the code appeared (filling, draining, heating, spinning), run one full power cycle (5 minutes off), and if the code returns, match the symptom to the closest documented family in the table above and check the tech sheet stored inside your machine for the model-specific definition.
Deep-dive guides for the most searched codes
Frequently asked questions
How to fix .20 error code on frigidaire dishwasher?
Start with the table above: find your code, run its first fix (usually a no-tool check — supply, filter, hose or load), then clear the code and run a short test cycle. If the same code returns, work through the cause list for that code before replacing parts.
How to fix error code on frigidaire gallery dishwasher?
Start with the table above: find your code, run its first fix (usually a no-tool check — supply, filter, hose or load), then clear the code and run a short test cycle. If the same code returns, work through the cause list for that code before replacing parts.
