Whirlpool, Maytag & Kenmore Washer OL Error Code: Meaning, Causes & Fix

Overload — the load size exceeds the washer's capacity (displayed oL on Cabrio/Bravos/Oasis top-loaders, stored as F70 on that platform and as F0E3 on newer F/E platforms).

OL (oL) means the control judged the load too heavy to proceed. The manuals' sequence is specific: the washer has attempted to fill and begin the wash cycle, and if it is overloaded it will drain any water and detergent that was added during the fill before stopping. It's a load-management report — too many items, or too many water-hungry heavy items (towels, denim, bedding) in one load. But both manufacturer charts carry a second branch: oL/F70 and F0E3 also post when the basket cannot disengage or cannot be turned — mechanical friction on the drive mechanism, or an item wedged between the basket and the tub — which is why OL on a modest load is a mechanical story, not a loading one. The display and the stored code are two spellings of this fault on the Cabrio platform: the panel flashes oL, and the same event is stored as F70. The Cabrio fault chart's wording is worth keeping in full because it carries both branches: 'oL flashes when the machine/motor control detects a load size that exceeds the washer's capacity' — and the fuller chart text adds 'or if the basket cannot disengage', naming mechanical friction on the drive mechanism as the alternative. Newer Whirlpool and Maytag top-loaders fold the same pair of conditions into F0E3: 'Fault is displayed when the main control detects a load size that exceeds the washer's capacity OR basket cannot be turned.' A Kenmore Elite showing OL is the Oasis — Kenmore's 110 (Whirlpool-built) twin of the Cabrio — and its manual prints the oL entry word for word as Whirlpool's, drain behaviour included. So across all four badges in this article's title, OL is one platform's report with one loading branch and one friction branch, and telling them apart is the whole diagnosis.

What causes the OL code on a Whirlpool washer?

Genuinely oversized load

A load size that exceeds the basket's capacity — the manuals judge it by outcome (the washer fills, attempts to begin, drains and stops), not by a fill fraction.

Waterlogged single items

One huge absorbent item reads as overload.

Basket cannot disengage / mechanical friction

Friction on the drive mechanism, or an item between the basket and the tub, prevents the basket disengaging or turning — the charts' second condition for this code.

A basket that cannot disengage after the drain step

On the Cabrio drive, agitation and spin need the basket to engage and disengage from the drive. The chart's second condition — basket cannot disengage, with mechanical friction on the drive mechanism — produces an honest oL on a load that is not oversized at all: the control tries to move a basket that is still coupled when it should be floating free, reads the resistance as excess load, and posts the overload code. The timing is the tell: this branch tends to appear as the cycle tries to move from one phase to the next, and it repeats at the same point on loads of any size, where a genuine overload varies with what you put in.

One waterlogged item that outweighs a full normal load

The manuals judge overload by load size against capacity, and water rewrites the arithmetic. A bath mat, a heavy rug, a single soaked blanket or a pair of saturated jeans can weigh more wet than a full mixed load, while looking like 'just one item' in the basket. The machine is not misreading: at fill and first movement it is moving that full wet weight. This is the branch behind most 'OL with only three things in it' reports — count the wet weight, not the items — and the cure is the same as any overload: split it, or wash the heavy item alone on its own cycle rather than adding more laundry to 'balance' an already-heavy basket.

Checks to run before you replace anything

1. Remove several items and rerun: OL gone = loading confirmed. Note that the machine drained the detergent away with the water, so add detergent again on the restart (the manuals' own instruction).
2. Note if OL appears on ordinary mixed loads repeatedly — that's the mechanical branch.
3. With power off, turn the basket by hand: a basket that cannot be turned freely is the friction branch, not a loading problem.
4. Use the restart itself as the test, exactly as the manuals write it: open the lid to clear the display, remove several items, add detergent (the machine drained the first dose away with the fill water), close the lid and press START/PAUSE. If the reduced load runs, the diagnosis was loading — no part is implicated, whatever the code felt like.
5. Watch where in the cycle OL appears. At fill/first movement, on a big or heavy load, is the loading branch. At the same transition point every time, on ordinary loads, is the disengage/friction branch — and a third pattern, OL appearing only on one particular item, is the waterlogged-single-item branch.
6. Separate OL from its neighbour uL before acting: uL is the unbalanced-load report that arrives near spin while the washer runs a correction routine; OL arrives early, after fill, and the washer drains and stops. Redistributing fixes uL; only removing weight (or removing friction) fixes OL.

How to fix the OL error code

1. Wash smaller loads; split heavy items across loads. Close the lid and press START/PAUSE (top-load) to restart after removing items.
2. If OL persists on modest loads, find the friction: check for items between the basket and the tub first, then drive-mechanism diagnosis (technician level if the basket won't turn).
3. For the friction branch, start with what costs nothing: look and feel for anything wedged between the inner basket and the outer tub (the F0E3 chart's own example of mechanical friction) and confirm the basket turns freely by hand with the power off. A basket that will not turn, or that grinds, is a technician diagnosis — forcing restarts against a locked basket wears the drive the code is protecting.

The part that usually fails: None for loading cases

Mechanical OL = whatever is creating the friction (a wedged item, basket or drive parts) — the manuals name the condition, not a single part.

How to reset / clear the OL code

On the oL platform: open the lid to clear the display, remove excess laundry, then restart the cycle. F0E3 clears the same way — excess removed, cycle restarted.

Whirlpool-built washers clear most codes with a power reset: unplug for 1 minute (top-load models with a cycle-status display sometimes need the lid opened and closed 6 times within 12 seconds after power is restored — the well-known lid-sequence calibration/clear procedure on VMW top-loaders). Codes stored in the control's fault history remain readable in diagnostic mode even after they stop showing on the display, which is why a code that 'went away' can still be found by a technician.

Why does the OL code keep coming back?

OL creeping into smaller and smaller loads over months = growing mechanical friction — get the drive inspected before it strands mid-cycle. OL that returns is telling you which branch you misread. Returning on the same bulky load is still loading — reduce further or split the heavy items; the code has no memory of fairness. Returning on progressively smaller, ordinary loads is the friction branch developing: basket disengagement getting worse, or an item working its way deeper between basket and tub. The pattern to act on early is OL plus any new mechanical sound — grinding, scraping, a basket that feels rough turning by hand — because that combination is the drive asking for inspection before the basket stops turning altogether and the overload report becomes a locked-rotor one.

How to stop OL coming back

• Genuinely oversized load: A load size that exceeds the basket's capacity — the manuals judge it by outcome (the washer fills, attempts to begin, drains and stops), not by a fill fraction.
• Waterlogged single items: One huge absorbent item reads as overload.
• Basket cannot disengage / mechanical friction: Friction on the drive mechanism, or an item between the basket and the tub, prevents the basket disengaging or turning — the charts' second condition for this code.

Retrieving stored fault codes on Whirlpool washers

Whirlpool platforms have a well-documented diagnostic mode. On front-load (Duet and later) models: with the machine in standby, press and hold any one button for 3 seconds, release for 3 seconds, repeat for a total of three holds — the display lights up and shows stored fault codes (F-codes with E-suffixes), which you step through with the same button. On top-load VMW models (most Maytag/Whirlpool/Kenmore top-loaders since ~2010): turn the cycle knob with a specific left/right sequence (commonly counterclockwise once, then clockwise three, counterclockwise one, clockwise one) until all status LEDs light, then use the knob to read fault codes as LED blink patterns. The tech sheet inside the cabinet lists the exact sequence and code chart for your model — use it rather than a generic chart, because code meanings shifted between Duet, Cabrio/Bravos and VMW generations.

Other Whirlpool washer error codes

See the full list on the Whirlpool Washer error codes hub.

Codes OL gets confused with

PF — Power failure — power was interrupted during operation (a customer notification code, not a breakdown and not a stored service fault). PF tells you the control lost power during a cycle: an outage, a tripped breaker, a plug knocked loose — or, when no house event explains it, control voltage too low or lost at the machine itself (the direct-drive service manual's F7E0 wording for the stored version of the same event).

RL — rL (remove load) — items were detected in the drum during the Clean Washer with affresh cycle. The manuals print it lowercase 'rL' and gloss it in brackets as (remove load); on some models the same condition is written F34. rL is documented in Whirlpool and Maytag front-load owner manuals, in two places: the troubleshooting table ('"rL" (remove load) appears in display — load detected in drum during Clean Washer with affresh cycle') and the Clean Washer cycle description itself.

F5E2 — Door/lid lock will not lock — the control cannot confirm the door (front-load) or lid (top-load) is locked, so the cycle cannot start. F5E2 means the control commanded the lock and the lock didn't confirm.

F21 — Long drain — the washer is taking too long to drain (Whirlpool's drain fault; F9E1 is its sibling rendering on Duet platforms). F21 means the control ran the drain pump and the water level didn't fall fast enough.

Working from a symptom instead? Read our troubleshooting guide for this problem.
