Samsung Washer Drain & Water-Out Error Codes (LC, LE): Meaning & Fixes

LC and LE are the two faces of one Samsung washer protection system: water going where it should not. Samsung groups LC and LE together, with 1E, 1C and LC1, as its water level or leakage family, where moisture is detected somewhere it does not belong or the level sensor reports water escaping. LC is the leak-detection rendering, most often a leak sensor in the base reporting real water under the machine. LE is the level-based rendering, where the control sees the water level falling, or never reaching its target, because water is leaving the tub outside the drain path. This guide separates the two codes, ranks their causes, and works through the checks in a safe order.

How Samsung watches for escaping water — and how to tell LC from LE apart

A Samsung washer monitors escaping water in two different ways, and the code on the display tells you which monitor tripped. Models fitted with leak detection watch the base of the machine: if water collects where the leak sensor sits, the control stops the cycle and reports the leak family, most commonly as LC on current displays. The second monitor needs no extra sensor at all — the control simply watches the water level through the pressure sensor. If the level falls during the wash when no drain was commanded, or never climbs to its target during fill, water must be leaving the tub somewhere, and many generations report that as LE. Samsung's own current support page files LC and LE in a single group — 1E, LE, 1C, LC, LC1 — described as a water level or leakage error, while its older top-load manuals define LE in level terms: the washer tried to fill but did not reach the proper water level, then drains for three minutes with the Power button disabled. Renderings vary by model generation, so the same escaping-water event can appear as LC on one machine and LE on another; neither code is a drain-pump code. For a washer that will not drain at all, Samsung uses a different family entirely — nd, 5E, SE, 5C and SC — covered elsewhere on this site. One warning before any check: a machine reporting escaping water stays off, unplugged, with both supply taps closed, until the water source is found. Never open panels or reach under a plugged-in washer standing in water.

Error code LC: leak detected

Error code LC on a Samsung washer means the leak detection has triggered: water has been detected where it should not be, most directly by a leak sensor sitting in moisture in the base of the machine, and the control has stopped the cycle to limit water damage. To fix the Samsung washer error code LC, do not start with the sensor — start with the water, because in most cases the sensor is telling the truth. The most likely cause is a weeping hose connection: inlet and drain hose joints loosen over years of vibration, their rubber washers harden, and a slow drip that never reaches the floor still finds its way into the base and trips the sensor. Second is the door seal on front-load models: a gasket torn, folded or lined with debris and hair leaks a small amount on every cycle, and those drips accumulate until the sensor reports them. Third is water that is not the washer's at all — a leaking supply tap behind the machine, a spill mopped toward it, or condensation — because the sensor cannot tell whose water it is sitting in. Fourth, and easy to miss, is drain installation: Samsung specifically warns that removing the drain hose holder can trigger automatic draining and error codes like LC, that the drain hose should be inserted only about 6 to 8 inches into the drain pipe, and that an airtight connection creates a vacuum that siphons water out of the tub, which the leak logic can read as escaping water. The owner checks follow that order. With the machine unplugged and the taps closed, pull it out carefully and look underneath and behind it for water, staining or a damp trail; dry everything completely, because a sensor left sitting in residual water keeps LC active even after the leak itself is fixed. Then run a short cycle and watch every hose joint, the inlet connections and the full door seal with a flashlight while the machine is under pressure — many leaks only weep during fill or drain. Check the detergent drawer housing as well, a classic slow-drip source on front-loaders, and run an empty cycle with no detergent to see whether suds appear: Samsung notes that too much detergent, or a non-HE detergent, can push foam and water where they do not belong, and repeated empty cycles until the suds are gone are its documented remedy. The fix is always the source, not the sensor: tighten or re-washer a weeping joint, replace a hose that is split or perished, replace a torn door gasket, and correct the drain hose depth, loop and holder so the machine cannot siphon. Once the area is fully dry and the cause is repaired, power-cycle the washer and run a short watched cycle; LC clears when the leak check passes. If LC returns, water is still arriving somewhere — test again under a full, heavy load, which flexes hoses and seals harder than a test rinse does.

Error code LE: low water level — water leaving, or never arriving

Error code LE on a Samsung washer is the level-based member of the same leak family: the control sees the water level falling unexpectedly during the cycle, or failing to reach its proper level during fill, and concludes that water is leaving the tub outside the drain path. Samsung's older manuals state it plainly — the washer has tried to fill but has not reached the proper water level — and when LE appears on those models the machine drains for three minutes while the Power button is disabled, so let that protective drain finish rather than fighting the controls. Samsung's regional code tables describe the same event as a natural drain or water leak with a low level detected during the cycle. So how to fix Samsung washing machine error code LE starts with a question: is water actually escaping, or is it being pulled out? Ranked by likelihood, the first cause is a genuine slow leak — a hose or connection weeping into the base, or a front-load door gasket dripping each cycle — which lowers the level exactly as a leak would, because it is one. Second is siphoning through the drain hose, the signature LE cause with no puddle at all: if the end of the drain hose sits lower than the base of the machine, or the hose is pushed too deep into the standpipe or sealed airtight into it, water drains away continuously by gravity and the level can never hold. Samsung's manual figures make the geometry concrete — front-load manuals place the drain hose outlet between 60 and 90 cm above the floor with a 65 cm standpipe recommended, US top-load manuals specify a standpipe no shorter than 39 inches (99 cm) and no longer than 96 inches (245 cm), and Samsung warns that a standpipe below the minimum lets water drain out mid-cycle by siphon. Third is an overfill-then-escape event, where a fill fault pushes water out of vents and the level behaviour reads as leakage. Fourth is oversudsing: excess foam confuses level sensing and can carry water out of the tub. The checks mirror the LC checks with the emphasis shifted to level and routing: look under and behind the machine and dry the area fully; watch a short cycle's hose joints and door seal with a light; then verify the drain hose installation end to end — holder fitted at the back of the machine, outlet at the documented height, inserted roughly 6 inches into the drain pipe rather than jammed deep, and never airtight. The fix follows the finding: repair the real leak at its washer, joint or gasket; re-route the drain hose to stop the siphon; and dry the base and sensor area thoroughly so the code can clear. Power-cycle once everything is dry and repaired, and LE clears when the leak and level check passes on a test cycle. One brand warning matters here: Samsung LE is not LG LE. On LG machines the same letters report a locked motor; on a Samsung washer LE is always this leak and low-level family, and reading it any other way sends the repair in entirely the wrong direction.

Shared diagnostic order for LC and LE

Because LC and LE report the same underlying event through different monitors, they share one diagnostic order, and working it in sequence prevents the classic mistake of replacing a sensor that was only reporting water. First, make the machine safe and gather evidence: unplug it, close both supply taps, note where in the cycle the code appeared — during fill, wash, drain or spin — and photograph the display, because on seven-segment displays letters and numbers are easy to confuse. Second, look for water before touching anything else: under the machine, behind it, along both inlet hoses and the drain hose, and inside the door gasket folds on a front-loader. A visible trail ends the diagnosis at its source. Third, if no leak shows, separate a real leak from a phantom one — dry the base and floor completely, then run a short, watched cycle; water that reappears under load is real, while a dry machine that still codes points at siphon routing or at suds. Fourth, audit the drain installation against Samsung's figures for your model type: holder in place, standpipe within the documented height range, hose inserted only a few inches and not sealed airtight. Fifth, run Samsung's suds test — an empty cycle with no additives; suds appearing means detergent overdose or a non-HE product is part of the fault, and empty cycles continue until they are gone. Only after those five steps does suspicion move to the sensing side itself — a sensor still sitting in trapped residual water, or a level sensor and its air hose misreporting — and that inspection, with panels off, is where owner work ends for most households. Keep notes as you go: which code showed, whether real water was found and where, and what the drain routing measured. On a repeat fault those notes are the diagnosis half-finished, and they stop a technician from re-checking the five steps you have already cleared. They also protect you from the opposite error — if the machine runs a full heavy load dry after a hose correction, the record of what changed is what proves the siphon, not the sensor, was the fault all along.

How to reset LC and LE — and what a reset cannot do

Neither LC nor LE has a button-sequence reset on a Samsung washer, and neither should: both codes clear when the machine re-tests and finds dry, level conditions, so the reset is the repair plus a power cycle. The correct sequence is to leave the machine unplugged with the taps closed while you find and fix the water source, dry the base and the sensor area completely — a sensor in residual water holds the code no matter how many times power is cycled — then restore power, open the taps, and run a short cycle while watching the joints and seal you repaired. On older models that respond to LE by draining for three minutes with the Power button disabled, wait that drain out; it is the control emptying the tub protectively, not a lockup. If the code clears and stays clear through a full load, the fault is closed. What a reset cannot do is dry the base for you, reseat a siphoning drain hose, or close a weeping joint — cycling power on a still-wet machine simply re-runs the same leak check and brings the same code back, and repeated restarts against an active leak risk turning a drip into floor damage. Treat a returning code after a proper dry-out as information, not defiance: water is still arriving from somewhere, and the next test should be run under a full, heavy load, which stresses every hose and seal harder than an empty rinse. Keep a simple log of each occurrence — date, cycle stage, code shown, and whether the floor was wet — because a pattern across three or four events separates an intermittent siphon from a steadily worsening leak far better than memory does.

When to call a professional

Call a professional when the water's source cannot be found but the base keeps getting wet: a technician running the machine on a test cycle, with panels off and the leak sensor area exposed, will trace a hairline leak — at the dispenser housing, the inlet valve body, a pump seal or a tub seam — faster and more safely than repeated guessing. Call as well when LC or LE returns after the hose joints have been re-washered, the gasket inspected, the drain routing corrected to Samsung's dimensions and the base fully dried, because the remaining suspects are internal: a split internal hose, a failing pump seal, or a leak or level sensor that itself needs testing and replacement. Stop and call immediately if water is reaching the power outlet, the floor is actively flooding, or the machine shows any electrical symptom alongside the code. Until the visit, keep the washer off with both taps closed and the area dried — an untraced leak rots floors and subfloors quietly, and that damage costs far more than the callout. Tell the technician which code your display shows, at what point in the cycle it appears, and whether any water was actually found; that combination is the difference between a leak hunt and a sensor test, and it shortens the visit considerably. Do not keep the machine in occasional service while you wait for the appointment, however tempting a small drip makes that seem: every cycle adds water to a base that has already reported it cannot stay dry, and a door gasket or hose that is weeping today can open up under a heavy load tomorrow. A washer paused for a few days is an inconvenience; a laundry-room floor replaced after months of hidden wetness is a renovation, and LC and LE exist precisely to keep the first from becoming the second.

Key takeaways

• Dry the base completely before judging any LC or LE repair — a leak sensor sitting in leftover water keeps the code active even when the leak itself is already fixed.
• Check the drain hose holder first on a newly moved or installed machine: Samsung warns that removing it can trigger automatic draining and an LC code, and a hose pushed deep into the standpipe siphons without leaking a drop.
• Photograph the code before resetting — on Samsung's seven-segment displays 1C, LC and 1E look alike at a glance, and the exact rendering tells the technician which monitor tripped.

Resetting the Samsung washer

On Samsung washers most fault codes clear with a power reset: switch the machine off, unplug it (or trip the breaker) for at least 5 minutes so the control board fully discharges, then restore power and run a short Rinse+Spin or a small test load. If the code was caused by a one-off condition — a kinked hose, an unbalanced load, a suds spike — it will not come back. If it returns on the next cycle, the control has detected the same fault again and the reset has only cleared the message, not the cause. Samsung does not use a button-combination 'master reset' on most models; the power cycle is the reset.
