Kenmore Washer Diagnostic Mode: How to Enter It & Read Stored Codes
Kenmore has no single diagnostic mode — it has two, inherited from its builders. Model prefix 110 (Whirlpool-built) uses the Whirlpool button-sequence method; prefix 796 (LG-built) uses LG's service mode and Smart Diagnosis. This page routes you by the model plate (under the lid or inside the door rim) and gives each platform's entry method, what the mode shows, and how to exit safely.
Find your builder first
The first three digits of the model number are the builder code: 110 = Whirlpool-built, 796 = LG-built (also common: 417 = Frigidaire-built laundry). Every diagnostic instruction that follows the wrong prefix is useless, so this 10-second check comes first.
110 (Whirlpool-built): the button method
The Whirlpool platform method: machine off (plugged in, panel dark); choose any three buttons on the console (except Power) and, within 8 seconds, press them in the sequence 1-2-3, 1-2-3, 1-2-3. All lights illuminate on success; from there the model cycles through stored fault codes and component tests with button/dial navigation per the tech sheet (tucked inside the cabinet or under the console). Record every stored code before clearing them — the history is the diagnostic gold.
796 (LG-built): service mode + Smart Diagnosis
LG-built Kenmores use LG methods: a model-specific button combination (commonly a pair of wash-option buttons held while pressing Power — the tech sheet names yours) enters the service test mode for component checks, and LG's Smart Diagnosis (app + phone audio/NFC) reads faults for models so equipped. Use the LG washer diagnostic guide on this site for the shared platform details.
Start at the model plate: Kenmore is a badge, and the first three digits name the builder
There is no single Kenmore diagnostic mode, and every frustrated attempt to enter one begins with skipping this step. Kenmore washers were built for Sears by other manufacturers, and the model number's first three digits — the prefix before the decimal point, found under the lid, inside the door rim or on the cabinet's model plate — identify which builder's platform is actually standing in your laundry room. Prefix 110 means a Whirlpool-built machine: its diagnostics are Whirlpool's, in two console generations covered below. Prefix 796 means an LG-built machine: its test mode is LG's Load Test Mode, a different procedure with a different purpose. The two platforms share almost nothing diagnostically — different entry, different displays, different ideas about what a 'stored code' even is — so a sequence that is gospel on a 110 machine does literally nothing on a 796, and vice versa. Ten seconds with the model plate is therefore not a preliminary to the diagnosis; it is the diagnosis's first and most load-bearing step. Everything after this section is labelled by platform: follow only your prefix's procedure.
Kenmore 110, display front loaders (Whirlpool-built): the three-button service mode
For 110 front loaders with a digital display — the Whirlpool-built platform these Kenmores share — the manufacturer's service documentation gives this entry. The washer must be empty and the control in the OFF state (plugged in, panel dark) before you begin. Close the door. Select any three different buttons on the console, except POWER, and remember them and their order: they become your 1st, 2nd and 3rd keys. Within 8 seconds of the first press, press and release them in sequence — 1, 2, 3 — and repeat the same sequence two more times (1-2-3, 1-2-3, 1-2-3 in total). Successful entry is unmistakable: the console beeps where a beeper is fitted and all console indicator lights turn on for 5 seconds. Stored fault codes then appear in the Estimated Time Remaining display, most recent code first; if no codes are stored, the display shows 88. On models without a display, the WASH LED flashes the code instead, in two sets of flashes, and stays lit if there are no stored codes. Working the mode: the 3rd key, pressed momentarily, advances to the next stored error code, and pressing and holding the 3rd key for 5 seconds clears the stored error codes — which is why you write every code down, in order, before you ever hold that key. The 2nd key starts the quick diagnostic test cycle on this platform, running the machine through its functions including drain. The mode times out after 10 minutes of inactivity or ends if AC power is removed. A console that will not enter after two careful attempts at the 8-second sequence is itself a finding — the tech sheet's route from there is its main-control test, not a faster third attempt.
Kenmore 110 top loaders (Whirlpool-built VMW platform): the knob sequence
The 110 top loaders on Whirlpool's VMW platform have no button trio — their service diagnostics are entered with the cycle selector knob, and the sequence is documented word-for-word in the model's tech sheet (the Kenmore 110 tech sheet, document W10828193, describes the same VMW procedure as Whirlpool's own W11448643 sheet). Set up first: washer in standby (plugged in, all indicators off), and after power is first applied, wait before starting. Then, with the whole sequence 'a' through 'e' completed within 6 seconds: RESET by rotating the cycle selector knob counterclockwise one or more clicks to clear any previous sequence; (a) rotate clockwise one click and wait half a second; (b) clockwise one click, wait half a second; (c) clockwise one click, wait half a second; (d) counterclockwise one click, wait half a second; (e) clockwise one click. Successful activation is shown by all the status LEDs (Fill/Wash, Rinse, Spin, Done — names vary by make and model) flashing on and off in half-second intervals; if they do not, the sheet's first suspicion is the 6-second window, so repeat the sequence before concluding anything. Turning the knob too fast or too slow genuinely affects entry. To read stored faults, turn the cycle selector knob until only the 'Done' LED is on and press START to enter Fault Code Display Mode: turn the knob clockwise to view the last 4 fault codes, most recent to oldest. To exit at any time, press and hold START for 3 seconds; the mode also exits after 5 minutes of inactivity or if the power cord is unplugged.
Reading the codes a 110 machine shows you: F and E, displays and flashing LEDs
Whirlpool-platform fault codes are two-part, and both halves matter: every code has an F number and an E number, where F identifies the suspect system or category and E identifies the suspect component within it — F9 E1 and F9 E2 are different repairs wearing similar coats. On display models the two halves alternate in the Estimated Time Remaining display (or show as 88/888 when the memory is empty). On the knob-controlled VMW models without a numeric display, the tech sheet's display method uses the status LEDs themselves: the codes are shown by alternating the LEDs in one-second intervals, the Fill (Sensing) LED tells you which half you are looking at — ON means the Fault (F) number is being represented, OFF means the Error (E) number — and the remaining Wash, Rinse, Spin and Done LEDs represent the number in binary, which the tech sheet's fault chart (pages 6-7 of W11448643) decodes. Two memory rules from the same sheet govern how you treat what you find. First, clearing: in Fault Code Display Mode, turn the knob until the status LEDs flash on and off, then press and hold START for 3 seconds to clear all fault codes and exit — a destructive step, so the written record comes first. Second, ageing: a fault code is removed from memory on its own if it does not reoccur after 10 consecutive wash cycles, which means a single old code in the memory may be history the machine has already forgiven, while the most recent code is the live story. The Automatic Test Mode on this platform ('Spin' LED on, START to begin, lid down, basket empty) runs an automatic test with water cycles through the major functions in a few minutes; watch where it hesitates and you have watched the fault happen.
Kenmore 796 (LG-built): Load Test Mode — a component test, not a stored-code vault
The 796 platform works on a different philosophy, and searching its test mode for a scrollable fault history will only confuse you: on these LG-built Kenmores, errors are displayed during operation when they occur, and the service mode exists to exercise components one at a time so you can watch each one work. The Kenmore 796 service manual's Load Test Mode entry is precise. The washer must be empty and the controls in the off state. Press the SPIN SPEED and SOIL LEVEL buttons simultaneously; while holding them, press the POWER button — the buzzer sounds twice to confirm entry. (On the 796.4172 manual's version, you then press the Steam button; model manuals vary in small steps, which is why yours governs.) Then press START/PAUSE repeatedly to step through the tests: the first state turns on all lamps and locks the door, and successive presses run tumble clockwise, low-speed spin, high-speed spin, the inlet valves in turn (prewash, main wash, hot water, bleach), tumble counterclockwise, the heater for a few seconds, and the drain pump, with the display showing rpm or the water level frequency at the relevant steps. The same manual gives a separate water level frequency check: press WASH/RINSE and DELAY START simultaneously and the digits show the level sensor's frequency. The manual's Error Mode Summary is symptom-based — water inlet error, unbalance error, drain error, overflow error, pressure sensor error, door open error, heating error, locked motor error, EEPROM error, power failure — each displayed while the fault is live, not archived for later scrolling. So on a 796, your diagnostic record is the code you saw during the failing cycle plus what each load-test step does when you command it; run the test with the drum empty, keep hands clear of a drum the test is about to spin, and treat any step that does not respond as that component's branch of the manual's troubleshooting charts.
Kenmore Elite, the 'diagnostic codes list' and the PDF question — answered by platform
Three searches bring most owners here, and each resolves once the platform does. 'Kenmore Elite washer diagnostic mode' first: Elite is a trim line, not a platform — Kenmore sold Elite washers on both builders' platforms, so an Elite badge tells you nothing diagnostic until the model plate does. A 110 Elite front loader enters the three-button service mode and reads stored codes on its display; a 110 Elite top loader uses the VMW knob sequence; a 796 Elite uses the Load Test Mode entry (SPIN SPEED and SOIL LEVEL held, POWER pressed, buzzer twice). Check the prefix, then follow that section of this page — the word Elite changes the features, never the entry. 'Kenmore washer diagnostic codes list' second: the authoritative list for your machine is the fault/error code chart in its own tech sheet or service manual, because codes are platform property — the F/E chart in a 110 machine's tech sheet (pages 6-7 in the W11448643 sheet) and the symptom-based Error Mode Summary in the 796 service manual are different documents describing different machines, and a generic all-Kenmore list mixes them into nonsense. Third, the PDF searches ('kenmore washer diagnostic codes pdf', including the top load version): this site does not host PDFs, and you do not need one — the tech sheet is a physical document packed inside the machine at the factory (the sheets carry the instruction 'DO NOT REMOVE OR DESTROY' because they are meant to live with the washer), and the procedures and reading methods in these sections reproduce what you need from it as ordinary text. Finish every diagnostic session properly on either platform: exit the mode (hold START for 3 seconds on VMW machines; power off on 796 machines), and know that the VMW tech sheet requires a calibration run after major drive work — its list is main control, basket, drive assembly, suspension, motor or capacitor replaced — because skipping calibration after those repairs manufactures fresh fault codes on a healthy machine.
Key takeaways
- The tech sheet inside the machine is the ultimate authority for your exact model's sequence and code order — retrieve it before experimenting.
- Exit diagnostic mode the way you entered (or power-cycle) and run a normal cycle afterwards to confirm the machine is back in user mode.
Resetting the Kenmore washer
Whirlpool-built washers clear most codes with a power reset: unplug for 1 minute (top-load models with a cycle-status display sometimes need the lid opened and closed 6 times within 12 seconds after power is restored — the well-known lid-sequence calibration/clear procedure on VMW top-loaders). Codes stored in the control's fault history remain readable in diagnostic mode even after they stop showing on the display, which is why a code that 'went away' can still be found by a technician.
