How to Reset Frigidaire Dishwasher Error Codes

Frigidaire dishwashers reset through the Start/Cancel pad for cycles and a power cut for the control. The Frigidaire-specific note owners need: the flood code i30 cannot be reset — it clears when the base dries — and the fill/drain codes (i10/i20) return on schedule if their water paths are still blocked.

Start/Cancel (the cycle reset)

Press Start/Cancel (hold ~3 seconds on many models): the cycle cancels and the machine drains. Use it before opening the filter or pulling the machine out, and as the clean starting state for any test.

The power reset

Breaker off 5 minutes for panel glitches/post-surge states. Restore, run a short cycle to verify.

Code behaviour

i30: no reset exists — base dry = cleared, base wet = code. i20: returns if the drain chain is still blocked. i10: returns if the fill chain still fails. ER (panel): Frigidaire's service documentation defines Er as a switch failure — a shorted keypad — and its fix order is the keypad-to-board connection first, then the keypad/console, then the board; a power reset only restarts the machine, and ER returns while a pad still reads closed.

The reset Frigidaire itself prints: Cancel, or the breaker for 5 minutes

Frigidaire's Use & Care manuals do not leave the reset to folklore — they print it as a footnote under the error code table, and it applies to every code in that table: if pressing the cancel button or turning power off at the breaker for 5 minutes does not resolve the problem, contact the Frigidaire Customer Care Center. Read that footnote as the whole Frigidaire reset philosophy in one sentence. There are exactly two sanctioned moves — Cancel at the pad, or a full five minutes without power at the breaker — and there is a defined end point: a code that survives both is not a code to reset harder, it is a service call the manufacturer has already authorised you to make. This is also why the breaker interval is five minutes and not the thirty seconds of internet habit: the manual's figure is the one the control was designed around, long enough for the electronics to fully discharge and reboot clean, and it is the same interval wherever the manual repeats the instruction. Anything beyond these two moves — button combinations, door-opening rituals, sequences borrowed from other brands — appears nowhere in Frigidaire's documentation for these machines.

How to reset a Frigidaire Gallery dishwasher error code

Owners search for a Gallery-specific reset because the Gallery badge sits on the door like a separate brand, but Frigidaire publishes no Gallery-only procedure: Gallery is a model line, not a control system, and Gallery machines follow the same reset their Use & Care manual prints — Cancel, or power off at the breaker for five minutes. What does differ across the Frigidaire range is which code language your machine speaks. Current Gallery models use the i-code table (i10, i20, i30 and the rest), where the manual's reset footnote applies directly. Earlier Gallery and Professional models of the letter-code generation display Er, uF, uo or CE instead, and for those codes the owner's guides print no reset at all — they list the codes as malfunction indications and direct owners to the Customer Care Center, because those codes report hardware states (a shorted keypad, a vent fault) that a reset cannot change. So the honest Gallery answer is two-part: for an i-code, Cancel or five minutes at the breaker is a genuine, manufacturer-printed reset; for a letter code, the same power cut restarts the machine and is worth one attempt, but the manual's own instruction for those codes is service, and a code that returns immediately is obeying its documentation, not defying your reset.

Code by code: what a reset does to i10, i20, i40 and iF0

Four of Frigidaire's i-codes are condition reports about water paths, and the manual pairs each with the condition to fix — the reset is only the receipt that proves you fixed it. i10 means a low fill has been detected, and Frigidaire's remedy is to look for a pinched water supply line or a water shutoff that is not completely opened. i20, i40 and iF0 are grouped together in the manual as clogged filters or a restricted drain line: check and clean both filters and the sump area, check for a pinched or blocked drain hose, and if the drain line attaches to a disposer, check that the knockout plug has been removed. Notice the pattern — none of these remedies mentions the control, because none of these codes is about the control. Cancel or the breaker will clear the display on all four, and all four will be back on the next cycle if the line is still pinched, the shutoff still half-closed, the filters still blinded or the disposer plug still in place. The reset's real function on this family is verification: fix the named condition, reset once, and run the machine — a code that stays away was reported honestly and fixed actually.

i30: the code with no reset at all

i30 is the exception owners most need to understand before they start pressing buttons: Frigidaire's manual defines it as a leak or overflow of water detected in the bottom pan, and there is no reset for it because the code is not stored in the control — it is being continuously reported by water sitting where water should never be. The manual's remedies are physical: look for loose connections at the water inlet valve, and ensure the unit is properly levelled (a machine leaning forward can spill water toward the pan on fills). While the pan holds water, many models also run the drain pump defensively, which owners misread as the machine 'refusing to reset' — it is the anti-flood system doing exactly its job. The clear, when it comes, is automatic: dry the base, fix the connection or the levelling that put the water there, and the code clears itself because its condition has cleared. Repeatedly power-cycling an i30 achieves nothing except delaying the drying, and cancelling the display on a machine that is still leaking converts a protective shutdown into an unmonitored leak.

i50, i60 and iC0: the codes the manual aims the reset at

Three i-codes are the genuine audience for the Cancel-or-breaker reset, because the manual writes the reset into their remedies. i50 reports a problem detected with the drain or wash motor, and Frigidaire's printed solution is the reset itself: pressing the cancel button or turning power off at the breaker for five minutes should clear this error code and the unit can be restarted — a latched motor-control state is precisely the kind of fault a full power discharge cures. i60 reports a problem with the water heating system, and iC0 a problem with the electronic control system; for both, the manual's table attaches the same footnote logic — try Cancel or five minutes at the breaker, and if that does not resolve the problem, service will need to be called. The distinction worth keeping: i50's remedy is the reset, full stop; i60 and iC0's remedy is the reset as a first and final test, because a heating circuit or a control system that still faults after a clean reboot has identified itself as hardware. One reset each, honestly attempted, is the complete manufacturer procedure for all three.

PF and Close: the two displays that are not error codes

Two entries in Frigidaire's manual sit in a separate table — User Instruction Codes — because they report states, not faults, and resetting them like errors wastes an afternoon. Close simply indicates the door has been left open or not properly latched; ensuring the door is properly latched clears the display, and the manual adds that this does not indicate a problem with your dishwasher and service will not need to be contacted. PF reports a power failure, in two grades the manual distinguishes: a soft power failure pauses the wash cycle and resumes it once power is restored if the door has not been opened, while a hard power failure means the unit will not operate until power is restored — and pressing start within 18 hours of the loss of power will resume at the point of cycle interruption. Owners meet PF after storms and breaker trips and read it as a breakdown; it is the machine telling you your electricity failed, not it. Neither display wants the breaker reset — Close wants a latched door, and PF wants, at most, a press of Start inside its 18-hour resume window.

ER and the letter codes: why they ignore the reset

On letter-code Frigidaire models, Er is the reset-resistant code owners meet most, and its resistance is definitional: Frigidaire's service documentation defines Er as a switch failure — a shorted keypad — declared when the control has verified a membrane pad closed for one minute. A reset restarts the control; the control re-reads the pad; the pad is still closed; Er returns. Nothing has gone wrong with the reset — the fault it reports is still physically present, and the manual tradition for these codes (the owner's guides list Er, uF, uo and CE and refer owners to the Customer Care Center without printing remedies) reflects that. Frigidaire's documented fix order for Er is hardware, in sequence: check the connection from the keypad to the main control board; if the connection is correct, replace the keypad — serviced as part of the console assembly; if the error still exists, replace the main control board. The vent codes uF and uo behave the same way for the same reason (a vent assembly state, not a stored message). Give a returning letter code one honest power reset to exclude a latched glitch, then stop resetting and follow its fix order.

After the reset: what the machine remembers (and what it doesn't)

Owners often follow a successful reset with a second worry — the machine seems to remember things, starting the same cycle they ran last week the moment Start is pressed. That one is by design, and Frigidaire's manual says so plainly: the dishwasher is programmed to remember your last cycle so you do not have to reset it each time, and to start the dishwasher using the same cycle and options selected on the previous wash, you just press the START pad. A power reset does not wipe that memory, and it isn't meant to — the reset clears fault states, not user preferences. The same manual documents the one preference with its own deliberate gesture: a favourite cycle is saved by selecting the cycle and options and holding the Favorite Cycle button for 3 seconds, until the LED over the pad lights. Knowing which behaviours are memory and which are faults saves a second round of troubleshooting: a dishwasher that offers yesterday's cycle is healthy and remembering; a dishwasher that brings back yesterday's error code is reporting, and it belongs to the fix-the-condition sections above, not to another reset.

When Frigidaire says stop resetting

Every reset on this page has the same manufacturer-defined expiry: Frigidaire's footnote sends you to the Customer Care Center when Cancel or five minutes at the breaker does not resolve the problem. That sentence is worth treating as an instruction rather than fine print, because it marks the exact point where continued resetting stops being troubleshooting. A second reset of the same code adds no information the first one didn't give; a third is usually just postponing a diagnosis the code has already delivered. The productive sequence is the manual's own: read the code before you clear it (photograph the panel — a cancelled cycle takes its evidence with it), fix the condition the code names where the manual names one, reset once, and verify on a real cycle. A code that clears and stays cleared through a full wash was a state, now closed. A code that returns has completed its report, and what it is asking for is the fix — or the service call Frigidaire already told you to make.

Key takeaways

• If the drain pump runs constantly with i30, that's the anti-flood doing its job — drying the base stops it, not the pad.
• Photograph the code before cancelling; cancelled cycles take their evidence with them.

Resetting the Frigidaire dishwasher

Frigidaire's i-series codes clear with a power reset: switch the breaker off for at least 5 minutes, restore power, and run a cycle. Leak code i30 is the exception in practice — it will not stay cleared while water remains in the base pan, because the float switch is still physically lifted.
